Integrated Stainless Steel Warmwasser Tank – Provides constant Warmwasser with a high level of Komfort.
-
Single Power Option: 24 kW – Suitable primarily für single-family houses, mostly used in new constructions.
-
Wall-Mounted Design – Saves space and allows easy installation in the home.
Komfort and Control
-
High Warmwasser Komfort
Thanks to the built-in tank, the boiler supplies Warmwasser quickly and at a constant temperature für baths, showers, or kitchen use. Just open the tap — and Warmwasser flows. -
Intuitive Operation
Clear LCD display with 6 main functions simplifies daily settings. -
Fernbedienung
With a Bosch WLAN controller like EasyControl and the appropriate key, the boiler can be easily managed per Fernzugriff über a smartphone or tablet app — ideal für a smart home setup. -
Automatic Power Modulation
The boiler automatically adjusts the burner output based on the household’s current demand, sorgt für energy-saving operation and achieving an Energieeffizienz rating of class A.
Technical Specifications
| Parameter | Value |
|---|---|
| Model/Type | GC5300iWT 24/48 23 |
| Nominal Heat Output (80/60°C) | 3 – 24 kW |
| Power at Low-Temperature Mode (30%) | 7.5 kW |
| Max Heizen Output | 22.7 kW |
| Max Supply Temperature | 82°C |
| Integrated Warmwasser Tank | Stainless Steel |
| Electrical Supply / Frequency | 230 V / 50 Hz |
| Degree of Protection | IPX4D |
| Net Weight | 72 kg |
| Dimensions (W x H x D) | 600 x 900 x 508 mm |
| Heizen Connections (Supply/Return) | R 3/4" Zoll |
| Gas Connection | R 3/4" Zoll |
| Flue and Air Pipe Diameter | 80 mm / 125 mm |
| Seasonal Heizen Efficiency | 93% |
| Warmwasser Heizen Efficiency | 83% |
| Color | Weiß |
| Order Number | 7716701581 |
Additional Benefits
-
Simple Solution für Modern Homes: ideal für smart homes with remote monitoring and control capabilities.
-
Low Energy Consumption: Maintains high efficiency even at partial loads.
-
Quiet and Reliable Operation: High manufacturing quality ensures a quiet and dependable performance within your home.
Bosch Condens 5300i WT offers excellent Warmwasser Komfort, Energieeffizienz, and easy operation — the perfect choice für new constructions and modern single-family homes.
