High temperature heat pump AUX - 3-phase ACHP-H08/4R3HA- 8 kW
High temperature heat pump AUX - 3-phase ACHP-H08/4R3HA- 8 kW
Show EU energy label
In stock — delivery time: approx. 4–6 business days
For F-gas units, the delivery time counts from receipt of the certified-installer documents.
Couldn't load pickup availability
Shipping & delivery
Shipping & delivery
Shipping within the EU is free from €100 order value — below that, the exact cost is shown at checkout; unfortunately we cannot deliver to islands.
Delivery time: items in stock usually arrive in approx. 4–6 business days; otherwise approx. 4–8 business days, for Bosch units currently approx. 8–11 business days. For split air conditioners and heat pumps containing F-gas, the delivery time counts from receipt of the certified-installer documents.
Compact units ship as parcels; large split and multi-split units ship by freight carrier with advance phone notice — kerbside delivery. Please check the shipment for visible transport damage on acceptance and note it with the driver.
Warranty & invoice
Warranty & invoice
You buy original goods with the full manufacturer warranty. Every order comes with an invoice showing VAT.
Withdrawal & returns
Withdrawal & returns
Consumers have a 14-day right of withdrawal. You will find all details in the withdrawal policy — you can declare withdrawal directly via the withdraw from contract page.
Old appliance take-back (§ 17 ElektroG)
Old appliance take-back (§ 17 ElektroG)
When you buy a new appliance of the same type, we take back your old electrical appliance free of charge. We ask you about this in the cart — for freight deliveries we coordinate collection or return with you.
Old appliances do not belong in household waste (crossed-out wheelie bin symbol). They contain recyclable and sometimes hazardous materials — separate collection protects health and the environment.
Manufacturer information
Manufacturer information
Manufacturer:
Moderni GmbH
Leinsamenweg 114
50933 Köln
Deutschland
Email:
office@jacobwarm.com
Contact:
jacobwarm.com
Refrigerant & installation
Refrigerant: R32 · Global warming potential (GWP): 675
Installation and commissioning may only be carried out by a certified specialist company (EU Regulation 2024/573). Commissioning is documented by your specialist company.
Technical information
|
|
ACHP-H08/4R3HA- 8 kW |
AUX ACHP-H10/4R3HA- 10 kW |
AUX ACHP-H12/5R3HA- 12 kw |
AUX ACHP-H14/5R3HA- 14 kw |
AUX ACHP-H16/5R3HA- 16 kw |
|
Wi-Fi: |
Yes |
||||
|
Cooling capacity (Min./Nom./Max): |
- / 8.45 / - kW |
- / 10 / - kW |
- / 12 / - kW |
- / 13.6 / - kW |
- / 15 / - kW |
|
Heating capacity (Min./Nom./Max): |
- / 8.4 / - kW |
- / 10 / - kW |
- / 12 / - kW |
- / 14 / - kW |
- / 16.1 / - kW |
|
Consumption power - cooling (Min./Nom./Max): |
- / 1.67 / - kW |
- / 2.8 / - kW |
- / 3 / - kW |
- / 3.78 / - kW |
- / 4.41 / - kW |
|
Consumption power - heating (Min./Nom./Max): |
- / 2.6 / - kW |
- / 3.23 / - kW |
- / 3.86 / - kW |
- / 4.67 / - kW |
- / 5.53 / - kW |
|
Nominal efficiency EER cooling: |
5.06 |
4.8 |
4 |
3.6 |
3.4 |
|
COP: |
3.19 |
3.1 |
3.11 |
3 |
2.91 |
|
SCOP: |
5.22 |
5.2 |
4.82 |
4.71 |
3.63 |
|
Energy label (Cooling / Heating) - Average climate: |
- / A+++ |
||||
|
Operation Range (Cooling): |
-5 ~ 52 °C |
||||
|
Operation Range (Heating): |
-25 ~ 35 °C |
||||
|
Circulating water temperature (cooling): |
5 ~ 25 °C |
||||
|
Circulating water temperature (heating): |
25 ~ 65 °C |
||||
|
Warranty: |
36 months |
||||
|
Refrigerant: |
R-32 |
||||
|
Power supply (Phase/Frequency/Voltage): |
1~/50/220-240 |
3~/50/380-415 |
|||
|
Dimensions (Indoor unit) |
790 x 420 x 270 H x W x L (mm) |
||||
|
Weight: |
38 kg |
39 kg |
|||
|
Sound Pressure - cooling (High/Nom./Low/Silent) |
31 / - / - / - dB |
||||
|
Sound Pressure - heating (High/Nom./Low/Silent) |
31 / - / - / - dB |
||||
|
Compressor type: (Outdoor unit) |
DC Twin Rotary |
||||
|
Dimensions: |
805 x 970 x 395 H x W x L (mm) |
870 x 1060 x 480 H x W x L (mm) |
|||
|
Weight: |
65 kg |
100 kg |
|||
|
Refrigerant piping - Liquid / Gas: |
9.52 / 15.9 mm (3/8" / 5/8") mm / inch |
||||
|
Sound Pressure - cooling (High/Nom./Low/Silent |
- / 45 / - / - dB |
- / 48 / - / - dB |
49 / - / - / - dB |
50 / - / - / - dB |
54 / - / - / - dB |
|
Sound Pressure - heating (High/Nom./Low/Silent |
- / 45 / - / - dB |
- / 48 / - / - dB |
49 / - / - / - dB |
50 / - / - / - dB |
54 / - / - / - dB |
|
Shipping package indoor |
|||||
|
Packages quantity: |
1 pc. |
||||
|
Package dimensions (HxWxD cm): |
40 x 100 x 50 |
98.5 x 51.5 x 35.5 |
40 x 100 x 50 |
79 x 42 x 27 |
|
|
Weight: |
45 kg |
||||
|
Shipping package outdoor |
|||||
|
Packages quantity: |
1 pc. |
||||
|
Package dimensions (HxWxD cm): |
110 x 90 x 50 |
88 x 53 x 108.5 |
110 x 100 x 55 |
88 x 53 x 108.5 |
|
|
Weight: |
69 kg |
112 kg |
105 kg |
112 kg |
|
Energy label for ACHP-H08/4R3HA - 8 kW
Energy label for ACHP-H10/4R3HA - 10 kW
Energy label for ACHP-H12/5R3HA - 12 kw
Technical data
| Energy efficiency class | - / A+++ (scale A+++ to D) |
|---|---|
| Power (kW class) | 7–12 kW |
| Noise level (indoor) | 31 dB(A) |
| Noise level (outdoor) | 45 dB(A) |
| Refrigerant | R32 |
| Global warming potential (GWP) | 675 |
| Colour | White |
For context: 31 dB(A) is in the “quiet” (whispering to a quiet home) range. Manufacturer figure — perceived loudness depends on operating mode, room and installation.
