High temperature heat pump AUX - 3-phase AUX ACHP-H16/5R3HA - 16 kw
Highest energy efficiency
AUX heat pumps achieve the highest energy class А+++ in heating mode and 35ºС hot water supply for the underfloor heating, which is fully sufficient to maintain the perfect temperature at home without creating a burden on your family budget.
Unmatched comfort at heating mode
AUX heat pumps maintain 9 levels of comfortable temperature depending on the atmospheric conditions. At every level, the water temperature in the underfloor heating installation and/or convectors will be automatically adjusted depending on the temperature outside to ensure maximum comfort in your home.
Wide operating range
The secure operation even in extremities is an important feature of AUX heat pumping systems. You can count on its stable operation in heating mode when the temperature outside drops to as low as -25ºС, and in cooling mode at as high as +52 ºС, giving you peace of mind both in the cold winter days and during the hot summer days too.
Control from any place
AUX heat pumps have an integrated remote control function via Wi-Fi. By using an application on your mobile phone you can easily adjust the temperature in your home, switch the heat pump on and off or control the hot water supply.
Disinfection (anti-legionella) function
The possible growth of bacteria (eg. legionella) in the water supply system is a fact that very often goes neglected. To ensure safe and healthy hot water supply, set the Disinfection function once a week. The heat pump can increase water temperature to 65ºС for 15 minutes, achieving sterilization as high as 99.99%.
Vacation mode
You can have peace of mind during your winter vacation by pressing just one single button. The heat pump enters Vacation mode, thus lowering energy consumption to minimum while protecting both the machine and your home against freezing.
Technical information
|
ACHP-H08/4R3HA- 8 kW |
AUX ACHP-H10/4R3HA- 10 kW |
AUX ACHP-H12/5R3HA- 12 kw |
AUX ACHP-H14/5R3HA- 14 kw |
AUX ACHP-H16/5R3HA- 16 kw |
Wi-Fi: |
Yes |
||||
Cooling capacity (Min./Nom./Max): |
- / 8.45 / - kW |
- / 10 / - kW |
- / 12 / - kW |
- / 13.6 / - kW |
- / 15 / - kW |
Heating capacity (Min./Nom./Max): |
- / 8.4 / - kW |
- / 10 / - kW |
- / 12 / - kW |
- / 14 / - kW |
- / 16.1 / - kW |
Consumption power - cooling (Min./Nom./Max): |
- / 1.67 / - kW |
- / 2.8 / - kW |
- / 3 / - kW |
- / 3.78 / - kW |
- / 4.41 / - kW |
Consumption power - heating (Min./Nom./Max): |
- / 2.6 / - kW |
- / 3.23 / - kW |
- / 3.86 / - kW |
- / 4.67 / - kW |
- / 5.53 / - kW |
Nominal efficiency EER cooling: |
5.06 |
4.8 |
4 |
3.6 |
3.4 |
COP: |
3.19 |
3.1 |
3.11 |
3 |
2.91 |
SCOP: |
5.22 |
5.2 |
4.82 |
4.71 |
3.63 |
Energy label (Cooling / Heating) - Average climate: |
- / A+++ |
||||
Operation Range (Cooling): |
-5 ~ 52 °C |
||||
Operation Range (Heating): |
-25 ~ 35 °C |
||||
Circulating water temperature (cooling): |
5 ~ 25 °C |
||||
Circulating water temperature (heating): |
25 ~ 65 °C |
||||
Warranty: |
36 months |
||||
Refrigerant: |
R-32 |
||||
Power supply (Phase/Frequency/Voltage): |
1~/50/220-240 |
3~/50/380-415 |
|||
Dimensions (Indoor unit) |
790 x 420 x 270 H x W x L (mm) |
||||
Weight: |
38 kg |
39 kg |
|||
Sound Pressure - cooling (High/Nom./Low/Silent) |
31 / - / - / - dB |
||||
Sound Pressure - heating (High/Nom./Low/Silent) |
31 / - / - / - dB |
||||
Compressor type: (Outdoor unit) |
DC Twin Rotary |
||||
Dimensions: |
805 x 970 x 395 H x W x L (mm) |
870 x 1060 x 480 H x W x L (mm) |
|||
Weight: |
65 kg |
100 kg |
|||
Refrigerant piping - Liquid / Gas: |
9.52 / 15.9 mm (3/8" / 5/8") mm / inch |
||||
Sound Pressure - cooling (High/Nom./Low/Silent |
- / 45 / - / - dB |
- / 48 / - / - dB |
49 / - / - / - dB |
50 / - / - / - dB |
54 / - / - / - dB |
Sound Pressure - heating (High/Nom./Low/Silent |
- / 45 / - / - dB |
- / 48 / - / - dB |
49 / - / - / - dB |
50 / - / - / - dB |
54 / - / - / - dB |
Shipping package indoor |
|||||
Packages quantity: |
1 pc. |
||||
Package dimensions (HxWxD cm): |
40 x 100 x 50 |
98.5 x 51.5 x 35.5 |
40 x 100 x 50 |
79 x 42 x 27 |
|
Weight: |
45 kg |
||||
Shipping package outdoor |
|||||
Packages quantity: |
1 pc. |
||||
Package dimensions (HxWxD cm): |
110 x 90 x 50 |
88 x 53 x 108.5 |
110 x 100 x 55 |
88 x 53 x 108.5 |
|
Weight: |
69 kg |
112 kg |
105 kg |
112 kg |
Energy label for ACHP-H08/4R3HA - 8 kW
Energy label for ACHP-H10/4R3HA - 10 kW
Energy label for ACHP-H12/5R3HA - 12 kw
