Inverter Air conditioner Mitsubishi Heavy Industries SRK71ZR-W + SRC71ZR-W

Jet technology
Mitsubishi Heavy Industries have applied an aerodynamic analysis used in the design of turbojet engines in order to develop their innovative Jet technology. The airflow generated by the JET Air Scroll system provides a large amount of air with minimal energy consumption, the air flow being powerful, even, silent (up to 25dB) and reaching the farthest corners of the room.

Powerful and efficient
Invertor air conditioner Mitsubishi Heavy Industries SRKZR-W / SRCZR-W is the perfect choice for large rooms which require high power when conditioning. With the push of a button you can activate the 3D AUTO function which executes 3 independent types of control on the air flow. As a result, you get even and quiet air flow that reaches every corner of the room. What you achieve is economical operation of the AC, and energy waste is minimized. Thanks to the automatic control of the flow and direction, comfortable heating and cooling of the whole room is achieved in the most efficient way.

Allergen-deactivating system
The Mitsubishi Heavy Industries SRKZR-W / SRCZR-W inverter air conditioner has two filters and a self-cleaning function in order to ensure a healthy environment in the room. The allergen-deactivating filter completely destroys pollen, parasites and allergens from our pets' furs. In addition, it neutralizes and kills all kinds of bacteria, moulds and virus and even released from the filter, they have already been deactivated.
The photocatalytic deodorizing filter prevents from unpleasant odours and the self-cleaning function does not allow moisture to be retained in the air
conditioner. Thanks to this, the air in the room stays clean and fresh.

Silence and restful sleep
When people sleep, it is not necessary to cool or heat too much. The Sleep Timer function provides moderate conditioning with a precise capacity management as well as additional energy saving. When Silent Mode is set, the conditioning takes care of your restful sleep working on a lower speed/capacity.
Adaptive predictive control The air conditioner automatically selects the working mode and temperature settings, depending on an approximate calculation and adjusts the frequency inverter. |
Economy mode |
Jet technology |
3D Auto You can choose the most suitable cooling or heating scheme with the push of a button. |
Automatic air distribution valves |
Saving the position of the valves |
Turning the air distribution valves into a vertical position |
Turning the air distribution valves into a horizontal position |
Allergen-deactivating system |
Self-cleaning function |
Allergen-deactivating filter |
Photocatalytic washable deodorizing filter |
Removable front panel |
Drying mode |
"Hi Power" mode The AC can work in "Hi Power" mode for 15 minutes. This mode is suitable for quick achievement of the desired temperature. |
Silent mode |
Night mode |
Weekly timer |
24 hour timer |
„Sleep” mode |
On/Off timer |
Comfortable start |
Child lock |
Positioning when mounting |
Microcomputer defrosting |
Self-diagnosis function |
Automatic function for restart |
Technical information
Model |
SRK63ZR-W + SRC63ZR-WR |
SRK71ZR-W + SRC71ZR-WR |
SRK80ZR-W + SRC80ZR-WR |
SRK100ZR-W + FDC100VNP |
||
Cooling capacity (Min./Nom./Max) |
1.2 / 6.3 / 7.4 kW |
2.3 / 7.1 / 7.7 kW |
2.3 / 8.0 / 9.0 kW |
2.4 / 10.0 / 10.5 kW |
||
Heating capacity (Min./Nom./Max) |
0.8 / 7.1 / 9.3 kW |
2.0 / 8.0 / 10.0 kW |
2.1 / 9.0 / 10.5 kW |
3.2 / 11.2 / 11.5 kW |
||
Consumption power - cooling (Min./Nom./Max) |
- / 1.63 / - kW |
- / 2.05 / - kW |
- / 2.35 / - kW |
- / 3.09 / - kW |
||
Consumption power - heating (Min./Nom./Max) |
- / 1.64 / - kW |
- / 2.06 / - kW |
- / 2.40 / - kW |
- / 3.28 / - kW |
||
Capacity (BTU): |
22 000 BTU |
24 000 BTU |
27 000 BTU |
|
||
Nominal efficiency EER cooling |
3.87 |
3.46 |
3.4 |
3.24 |
||
Seasonal efficiency SEER cooling |
8.1 |
7.2 |
6.6 |
6.6 |
||
COP |
4.33 |
3.88 |
3.75 |
3.41 |
||
SCOP |
4.7 |
4.5 |
4.4 |
4.4 |
||
Energy label (Cooling / Heating) - Average climate |
A++ / A++ |
A++ / A+ |
A++ / A+ |
A++ / A+ |
||
Operation Range (Cooling) |
-15 ~ 46 °C |
-15 ~ 46 °C |
-15 ~ 46 °C |
-15 ~ 46 °C |
||
Operation Range (Heating) |
-15 ~ 24 °C |
-15 ~ 24 °C |
-15 ~ 24 °C |
-15 ~ 24 °C |
||
Suitable for rooms up to |
44 square meters |
49 square meters |
56 square meters |
69 square meters |
||
Warranty |
36 months |
36 months |
36 months |
36 months |
||
Refrigerant |
R-32 |
R-32 |
R-32 |
R-32 |
||
Power supply (Phase/Frequency/Voltage) |
1~/50/220-240 |
1~/50/220-240 |
1~/50/220-240 |
1~/50/220-240 |
||
|
|
Indoor unit |
||||
Dimensions |
339 x 1197 x 262 H x W x L (mm) |
339 x 1197 x 262 H x W x L (mm) |
339 x 1197 x 262 H x W x L (mm) |
339 x 1197 x 262 H x W x L (mm) |
||
Weight |
15.5 kg |
16 kg |
17 kg |
17 kg |
||
Sound Pressure - cooling (High/Nom./Low/Silent) |
44 / 39 / 35 / 25 dB |
44 / 41 / 37 / 25 dB |
47 / 44 / 39 / 26 dB |
48 / 45 / 40 / 27 dB |
||
Sound Pressure - heating (High/Nom./Low/Silent) |
44 / 38 / 34 / 28 dB |
46 / 39 / 35 / 28 dB |
47 / 41 / 36 / 29 dB |
48 / 43 / 38 / 30 dB |
||
|
|
Outdoor unit |
||||
Dimensions |
640 x 800 x 290 H x W x L (mm) |
750 x 880 x 340 H x W x L (mm) |
750 x 880 x 340 H x W x L (mm) |
845 x 970 x 370 H x W x L (mm) |
||
Weight |
45 kg |
57 kg |
59 kg |
70 kg |
||
Refrigerant piping - Liquid / Gas |
6.35 / 12.7 mm (1/4" / 1/2") |
6.35 / 15.9 mm (1/4" / 5/8") mm / inch |
9.52 / 15.9 mm (3/8" / 5/8") mm / inch |
6.35 / 15.9 mm (1/4" / 5/8") |
||
Sound Pressure - cooling (High/Nom./Low/Silent) |
- / 54 / - / - dB |
- / 53 / - / - dB |
- / 56 / - / - dB |
- / 57 / - / - dB |
||
Sound Pressure - heating (High/Nom./Low/Silent) |
- / 54 / - / - dB |
- / 51 / - / - dB |
- / 55 / - / - dB |
- / 61 / - / - dB |
Energy label for Mitsubishi Heavy Industries SRK71ZR-W / SRC71ZR-W
Declaration of conformity for Mitsubishi Heavy Industries SRKZR-W
