Mitsubishi Heavy Industries SRR35ZS-W + SRC35ZS-W1 Ducted Air Conditioner — 12 000 BTU Inverter Air Conditioner
The Mitsubishi Heavy Industries SRR35ZS-W + SRC35ZS-W1 Ducted Air Conditioner is a wall-mounted inverter split air conditioner for rooms up to approximately 26 m². With 12 000 BTU cooling capacity, modern R-32 refrigerant and energy-efficient inverter technology, it provides reliable year-round comfort. Detailed technical data verified against the manufacturer feed is listed below.
Verified Specifications
- Cooling capacity (min / nom / max): 1.0 / 3.5 / 3.9 kW
- Heating capacity (min / nom / max): 1.5 / 4.2 / 5.2 kW
- Power input — cooling (min / nom / max): - / 0.98 / - kW
- Power input — heating (min / nom / max): - / 1.03 / - kW
- Cooling capacity (BTU): 12 000
- SEER (seasonal cooling efficiency): 6.31
- SCOP (seasonal heating efficiency): 4.25
- Energy class — cool / heat (temperate climate): A++ / A+
- Operating temperature — cooling: -15 ~ 46 °C
- Operating temperature — heating: -15 ~ 24 °C
- Suitable for rooms up to: 26 m²
- Warranty: 36 months
- Refrigerant: R-410A
- Power supply (phase / frequency / voltage): 1~/50/220-240
Indoor Unit
- Dimensions: 200 x 750 x 500 H × W × D (mm)
- Weight: 21 kg
- Sound level — cooling (high / nom / low / silent): 38 / 34 / 31 / 25 dB (A)
- Sound level — heating (high / nom / low / silent): 41 / 38 / 35 / 29 dB (A)
Outdoor Unit
- Dimensions: 595 x 780 x 290 H × W × D (mm)
- Weight: 35 kg
- Pipe connections (liquid / gas): 6.35 / 9.52 mm (1/4" / 3/8")
- Sound level — cooling (high / nom / low / silent): - / 50 / - / - dB (A)
- Sound level — heating (high / nom / low / silent): - / 50 / - / - dB (A)
About Mitsubishi Heavy Industries
AUX is a Chinese specialist manufacturer of inverter air conditioners with a strong focus on energy efficiency, smart-home integration and competitively-priced premium technology. AUX units use modern R-32 refrigerant in all current models and include Wi-Fi as standard.
Delivery & Installation
EU-wide Die aktuelle Lieferzeit finden Sie in den Lieferangaben auf dieser Seite. Installation must be performed by a certified HVAC technician (F-gas certification required). On request we can recommend qualified installation partners in your region.
Advice & Datasheet on Request
Questions about the right BTU capacity for your room, multi-split compatibility, or additional accessories? Our team is happy to advise — by phone or email.
📧 office@jacobwarm.com
📞 +49 221 29293710
🕘 Mon–Fri 8:00–16:00 CET
Technical data
| Model | SRR35ZS-W |
|---|---|
| Energy efficiency class | A++ / A+ (scale A+++ to D) |
| Power (BTU class) | 12000 |
